Laser Power Supply Circuit Schematic

Laser

Notes

1. T1 is an ordinary 9V 1A transformer connected backwards for step up.

2. R1 MUST be installed on a LARGE heatsink. A good heatsink is the metal case the supply is built in.

3. R2 Protects the laser tube from excess current. It should be soldered directly to the anode terminal on the tube. To find R2, start with a 500K 10W resistor and work down until the tube lights and remains stable.

4. If you have trouble with the tube not starting easily, use a longer anode lead that is wrapped around the tube.

5. Depending on the transformer you use, the circuit may or may not work. I cannot guarantee the operation of this circuit. Build at your own risk. Some transformers contain very few secondary windings which will quickly saturate the core and basically act like a direct short. The more secondary windings (that is, primary in this circuit) the better.
